HWATEK WIRES AND CABLE CO.,LTD.
|
Product Details:
Payment & Shipping Terms:
|
| Conductor: | Tinned Copper | Insulation: | PVC |
|---|---|---|---|
| Jacket: | PVC | Cable Shape: | Round |
| Application: | Industrial, Comsumer Electrics, Medical, EV Charging, Green Energy Etc | Packing: | Packed In Reels |
| Volatge: | 30V | Temperature: | -40~105℃ |
| PN: | HT2401391 | ||
| High Light: | 5C copper stranded cable,PVC jacket copper stranded cable,300V copper stranded cable |
||
| ITEM | 5C×12AWG(65/0.254T)+W | ||||
| CONDUCTOR | Material | Tinned copper stranded | |||
| Size | 65/0.254mm | ||||
| O.D.(Ref) | 2.36mm | ||||
| INSULATION | Material | PVC | |||
| Min.average thickness | 0.38mm | ||||
| Min.thickness at any point | 0.33mm | ||||
| O.D. | 3.20±0.15mm | ||||
| CABLING | Filler | Optional | |||
| Material | Non-woven,≥25% | ||||
| Assembly | 5C×12AWG(65/0.254T)+W | ||||
| BRAID | Material | / | |||
| Size | / | ||||
| JACKET | Material | PVC(oil&water resistant) | |||
| Min.average thickness | 0.76mm | ||||
| Min.thickness at any point | 0.61mm | ||||
| O.D. | 10.80±0.30mm | ||||
Conductor Tinned copper stranded
Cross section 5C×12AWG(65/0.254T)
Construction 65/0.254mm
Elongation ≥100%
Strand Dia.(Ref.) 2.36mm
Aged condition 136±1℃×168h
Insulation PVC
Nom.Thickness 0.38mm
Min.Thickness 0.33mm
Insulation Dia. 3.20±0.15mm
Insulation colour natural, black,green,red,blue
Assembly Insulation: 1.brown 2.blue 3.black 4.white 5.yellow/green
Jacket PVC
Reference standard:UL2725
Nom.Thickness 0.76mm
Min.Thickness 0.61mm
Outer Dia. 10.80±0.30mm
Colour per request
UL758-E258652-20060111A-CertificateofCompliance(2)...
| ELECTRICAL CHARACTERISTICS | |
| Rated voltage:30V | |
| Rated temperature:-40~105℃ | |
| Max.conductor DC resistance(20℃) | |
| 8.96Ω/km |
