HWATEK WIRES AND CABLE CO.,LTD.
|
Product Details:
Payment & Shipping Terms:
|
| Conductor: | Tinned Copper | Insulation: | PVC |
|---|---|---|---|
| Jacket: | PVC | Cable Shape: | Round |
| Application: | Industrial, Comsumer Electrics, Medical, EV Charging, Green Energy Etc | Packing: | Packed In Reels |
| Volatge: | 30V | Temperature: | -40~105℃ |
| PN: | HT2401238 | ||
| Highlight: | oil resistant UL2517 cable,water resistant UL2517 cable,2C 18AWG UL2517 cable |
||
| ITEM | 2C×18AWG+W | ||||
| CONDUCTOR | Material | Tinned copper stranded | |||
| Size | 16/0.254mm | ||||
| O.D.(Ref) | 1.17mm | ||||
| INSULATION | Material | PVC | |||
| Min.average thickness | 0.38mm | ||||
| Min.thickness at any point | 0.33mm | ||||
| O.D. | 1.80±0.10mm | ||||
| CABLING | Filler | Optional | |||
| Material | Non-woven,≥25% | ||||
| Assembly | 2C×18AWG+W | ||||
| BRAID | Material | / | |||
| Size | / | ||||
| JACKET | Material | PVC(oil&water resistant) | |||
| Min.average thickness | 0.76mm | ||||
| Min.thickness at any point | 0.61mm | ||||
| O.D. | 5.30±0.30mm | ||||
Conductor Tinned copper stranded
Cross section 2C×18AWG+W
Construction 16/0.254mm
Elongation ≥100%
Strand Dia.(Ref.) 1.17mm
Aged condition 136±1℃×168h
Insulation PVC
Nom.Thickness 0.38mm
Min.Thickness 0.33mm
Insulation Dia. 1.80±0.10mm
Insulation: 1.black 2.red
Jacket PVC
Reference standard:UL2725
Nom.Thickness 0.76mm
Min.Thickness 0.61mm
Outer Dia. 5.30±0.30mm
Colour per request
UL758-E258652-20060111A-CertificateofCompliance(2)...
| ELECTRICAL CHARACTERISTICS | |
| Rated voltage:300V | |
| Rated temperature:-40~105℃ | |
| Max. DC conductor resistance(20℃):23.2Ω/km |
Company Profiles
Founded in 2004 with 9 million USD capital investment, our HQ factory in Kunshan covers 14980 square meters.
In 2020 we established our Nantong facility with 100 million RMB capital investment which covers 34000 square meters.
With ISO9001, ISO14001, IATF16949, ISO13485 system certificates, all of our products have passed CCC, UL, CUL, CE, CSA, ETL safety certificates. We are working with global customers in various fields through our well-established sales system based on the management principal HONESTY, INNOVATION and ENVIRONMENTAL PROTECTION.
Certificates
Production Progress
Shipping
FAQ
1. Q:What can you supply?
A: We do produce consumer electronics wires, hock up wires, industrial cables, robot cables, ev charging cables, new/green energy cables.
2. Q: What are the certificates do you get?
A: We have UL, CE, 3C, Dekra, CQC, TUV, Rohs, Reach, ETL certificates.
3. Q:Can we get samples before ordering?
A: Yes, we are willing to arrange samples for you.
4. Q: What's your lead time?
A: Normally we can finish you orders in 2-3 weeks, and 5-6 weeks in peak season.
5. Q. How can you guarantee the product quality?
A: Always a pre-production sample before mass production and final Inspection before shipment.
