Network Camera Outdoor Communication Cable UTP Cat5e CAT6
Product Details
Tinned Copper Communication Cable
,CAT6 Communication Cable
,Cat5e Communication Cable
UTP Cat5e, CAT6 Network SFTP FTP UTP Shielded LAN Internet Camera Outdoor Communication Cable
Product Description
Products are used in 100Base-T4, 100Base-TX, 1000Base-T(Gigabit internet), 155Mbps ATM,622Mbps ATM.
Application: communication and signal control systems
Application standard: UL444
Product character:
High-speed transmission, strong shielding property
Flame rate: CMX, CM, CMG, CMR
Standard thickness, easily strip and cut
Constructure:
Stranded or Solid copper, tinned or bare conductor, copper jacket steel conductor
PE insulation
PVC jacket
| Product number | Conductor | Insulation | Construction No.of Pairs | Shield | Braid Shield | Jacket |
| NO./mm | Material | Material | No./No./mm | Nom. Dia.mm | ||
| HT-CAT5-UTP001 | 1/0.51 | 0.95 | UTP 4 | - | - | 5.10 |
| HT-CAT5-FTP001 | 1/0.53 | 1.00 | FTP 4 | AL-Mylar | - | 5.60 |
| HT-CAT5-SUTP001 | 1/0.53 | 1.00 | S-UTP 4 | AL-Mylar | 16/6/0.10 | 6.00 |
| HT-CAT5-SFTP001 | 1/0.53 | 1.00 | S-FTP 4 | AL-Mylar | 16/6/0.10 | 6.00 |
Company Profiles
Founded in 2004 with 9 million USD capital investment, our HQ factory in Kunshan covers 14980 square meters.
In 2020 we established our Nantong facility with 100 million RMB capital investment which covers 34000 square meters.
With ISO9001, ISO14001, IATF16949, ISO13485 system certificates, all of our products have passed CCC, UL, CUL, CE, CSA, ETL safety certificates. We are working with global customers in various fields through our well-established sales system based on the management principal HONESTY, INNOVATION and ENVIRONMENTAL PROTECTION.
Certificates
Production Progress
Shipping
FAQ
1.Q:What can you supply?
A: We do produce consumer electronics wires, hock up wires, industrial cables, robot cables, ev charging cables, new/green energy cables.
2.Q: What are the certificates do you get?
A: We have UL, CE, 3C, Dekra, CQC, TUV, Rohs, Reach, ETL certificates.
3.Q:Can we get samples before ordering?
A:Yes, we are willing to arrange samples for you.
4.Q: What's your lead time?
A: Normally we can finish you orders in 2-3 weeks, and 5-6 weeks in peak season.
5.Q. How can you guarantee the product quality?
A: Always a pre-production sample before mass production and final Inspection before shipment.
