HWATEK WIRES AND CABLE CO.,LTD.
|
Product Details:
Payment & Shipping Terms:
|
| Conductor: | Bare Copper | Insulation: | EVI-2 |
|---|---|---|---|
| Jacket: | EVM-1 | Cable Shape: | Round |
| Application: | Industrial, Comsumer Electrics, Medical, EV Charging, Green Energy Etc | Packing: | Packed In Reels |
| Volatge: | 450/750V | Temperature: | 90℃ |
| High Light: | EVM-1 Jacke EV Charging Cable,EVI-2 Insulation EV Charging Cable |
||
| Conductor | Bare copper stranded | |||
| Cross section | 6mm2 | 0.75mm2 | ||
| Construction | 189/0.20mm | 40/0.15mm+Tinsel+Kevlar | ||
| Strand Dia. | 3.40mm | 1.30mm | ||
| Insulation | EVI-2 | EVI-2 | ||
| Nom.Thickness | 0.70mm | 0.41mm | ||
| Min.Thickness | 0.53mm | 0.33mm | ||
| Insulation Dia. | 4.80±0.20mm | 2.20±0.10mm | ||
| Insulation colour | A1.brown A2.yellow/green A3.blue A4.gray A5.black | B1.red B2.white | ||
| Filler | Optional | |||
| Material | Nonwoven tape,25% min. | |||
| Assembly | 5C×6mm2+2C×0.75mm2+W | |||
| Jacket | EVM-1 | |||
| Nom.Thickness | 1.40mm | |||
| Min.Thickness | 1.09mm | |||
| Outer Dia. | 16.60±0.35mm | |||
| Colour | Black | |||
A:5C×:6mm2 B:2C×0.75mm2 Jacket
Conductor Bare copper stranded
Cross section 6mm2 0.75mm2 Tensile strength ≥20MPa
Construction 136/0.15mm+Tinsel+ Kevlar 28/0.15mm+Tinsel+ Kevlar
Elongation ≥300%
Strand Dia.(Ref.) 3.40mm 1.3mm
Aged condition 110±1ºC×168h
Insulation EVI-2 Percent of original tensile strength ±30%
Nom.Thickness 0.70mm 0.41mm
Min.Thickness 0.53mm 0.33mm
Insulation Dia. 4.80±0.20mm 2.20±0.10mm
Insulation colour
A.brown,blue,yellow/green,gray,black B.red
Filler PP rope
Assembly 5C×6mm2+2C×0.75mm2+W
Jacket EVM-1
Reference standard:EN50620-2017
Nom.Thickness 1.4mm
Min.Thickness 1.09mm
Outer Dia. 16.60±0.35mm
Colour per request
Company Profiles
Founded in 2004 with 9 million USD capital investment, our HQ factory in Kunshan covers 14980 square meters.
In 2020 we established our Nantong facility with 100 million RMB capital investment which covers 34000 square meters.
With ISO9001, ISO14001, IATF16949, ISO13485 system certificates, all of our products have passed CCC, UL, CUL, CE, CSA, ETL safety certificates. We are working with global customers in various fields through our well-established sales system based on the management principal HONESTY, INNOVATION and ENVIRONMENTAL PROTECTION.
Certificates
Production Progress
Shipping
FAQ
1. Q:What can you supply?
A: We do produce consumer electronics wires, hock up wires, industrial cables, robot cables, ev charging cables, new/green energy cables.
2. Q: What are the certificates do you get?
A: We have UL, CE, 3C, Dekra, CQC, TUV, Rohs, Reach, ETL certificates.
3. Q:Can we get samples before ordering?
A: Yes, we are willing to arrange samples for you.
4. Q: What's your lead time?
A: Normally we can finish you orders in 2-3 weeks, and 5-6 weeks in peak season.
5. Q. How can you guarantee the product quality?
A: Always a pre-production sample before mass production and final Inspection before shipment.
