HWATEK WIRES AND CABLE CO.,LTD.
|
Product Details:
Payment & Shipping Terms:
|
| Conductor: | Bare Copper, Tinned Copper, Silver Plated Copper | Insulation: | FRPE |
|---|---|---|---|
| Jacket: | FRPE | Cable Shape: | Round |
| Application: | Industrial, Comsumer Electrics, Medical, Etc | Packing: | Packed In Reels |
| Volatge: | 1000V | Temperature: | 80℃ |
| High Light: | UL 10513 FRPE Cable,Stranded FRPE Cable,UL 10513 Stranded Cable |
||
UL 10513, 21254 sun resistance 2C × 14AWG Tinned copper stranded FRPE Cable
Product Description
Application: Internal wring or external interconnection of electronic equipment.
Product character:
1) Nominal voltage: 1000V
2) Rated temperature:80℃
3) Conductor: Tinned plated copper
4) Insulator:FRPE
5) Operating temperature : -20ºC (-40ºC when fixed) to +80ºC
6) Colours: Insualtion:A.Green,White B1.Red,B2.Black
7) Use: USB 2.0 COMPLIANT
8) Standard: UL21254
UL758 -E258652-20060111-CertificateofCompliance-1....
| ITEM | 2C×14AWG(41/0.254T) | ||||
| CONDUCTOR | Material | Tinned copper stranded | |||
| Size | 41/0.254mm | ||||
| O.D.(Ref) | 1.88 | ||||
| INSULATION | Material | FRPE | |||
| Min.average thickness | 0.35mm | ||||
| Min.thickness at any point | 0.28mm | ||||
| O.D. | 2.70±0.10mm | ||||
| JACKET | Material | FRPE(sun resistance) | |||
| Min.average thickness | 0.76mm | ||||
| Min.thickness at any point | 0.61mm | ||||
| O.D. | 7.20±0.20mm | ||||
Conductor : stranded, tinned or bare copper
Construction
Insulation:FRPE
Insulation:gray,black
Jacket: FRPE
Application
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines,
Standards
RoHS,REACH Compliant,
Technical data
Rated voltage:1000V
Rated Temperature: 80℃
Flame: FT1
Voltage withstand test:AC 2.0kV/1min
Properties
Effectively resist electromaganetic interference
Excellent insulation performance
Extensively oil resistant
Flexible
