Double Shielded 30V 15pin AWG32 PUR Flexible Cable Custom Made

Double Shielded 30V 15pin AWG32 PUR Flexible Cable Custom Made
Double Shielded 30V 15pin AWG32 PUR Flexible Cable Custom Made

Large Image :  Double Shielded 30V 15pin AWG32 PUR Flexible Cable Custom Made

Product Details:
Place of Origin: China
Brand Name: Hwatek
Certification: CE, RoHS, Reach
Model Number: NOUL
Payment & Shipping Terms:
Minimum Order Quantity: 1220m
Price: To be negotiated
Packaging Details: Packed in rolls or reels
Delivery Time: 4-6 Weeks
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 100km per day
Detailed Product Description
Conductor: Tinned Copper Stranded Insulation: ETFE
Jacket: PVC Cable Shape: Round
Application: Industrial, Comsumer Electrics, Medical, Etc Packing: Packed In Reels
Volatge: 30V Temperature: 80℃
High Light:

Double Shielded Flexible Cable

,

Custom Made Flexible Cable

,

30V Industrial Flexible Cable

double-shielded 80℃ 30V 15pin ,AWG32 PUR custom-made flexible cable



Product Description

Application: Internal wring or external interconnection of electronic equipment.
Application standard: UL758&UL1581
Product character:

Tensile strength:≥10.3MPa    Elongation:≥100%

Aged condition:136±1℃×168h

Percent of original tensile strength: ≥70%

Percent of original elongation: ≥65%



UL758 -E258652-20060111-CertificateofCompliance-1....

Construction

Conductor     Tinned copper stranded
Cross section     32AWG
Construction     7/0.08mm
Strand Dia.     0.24mm
Insulation     ETFE
Nom.Thickness     0.08mm
Insulation Dia.     0.40±0.08mm
Insulation colour 1.black 2.brown 3.red 4.orange 5.yellow 6.green
7.blue 8.violet 9.gray 10.white 11.pink 12.natural
13.darkt red 14.darkt green 15.darkt blue
Filler     Optional
Material     Al-mylar
Assembly     15C×32AWG+A
Spiral     Tinned copper,0.10mm 90%Min.
Inner jacket     PVC
Nom.Thickness     0.38mm
Outer Dia.     3.20±0.20mm
Colour     Gray
Spiral     Tinned copper,0.10mm 80%Min.
Material     Al-mylar
Jacket     PUR
Nom.Thickness     0.38mm
Outer Dia.     4.50±0.20mm
Colour     Black



Insulation:ETFE
Conductor : Tinned copper stranded
Construction

Insulation: 1.black 2.brown 3.red 4.orange 5.yellow 6.green
7.blue 8.violet 9.gray 10.white 11.pink 12.natural
13.darkt red 14.darkt green 15.darkt blue

Jacket :Black

Jacket: PUR

Application
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines,

Standards
International: UL758 , UL1581, UL2464
RoHS,REACH Compliant,

Technical data
Rated voltage:
30V
Rated Temperature: 80℃
Voltage withstand test:AC 0.5kV/1min

Properties
Effectively resist electromaganetic interference
Excellent insulation performance
Extensively oil resistant
Flexible

Double Shielded 30V 15pin AWG32 PUR Flexible Cable Custom Made 0Double Shielded 30V 15pin AWG32 PUR Flexible Cable Custom Made 1Double Shielded 30V 15pin AWG32 PUR Flexible Cable Custom Made 2



Double Shielded 30V 15pin AWG32 PUR Flexible Cable Custom Made 3
