HWATEK WIRES AND CABLE CO.,LTD.
|
Product Details:
Payment & Shipping Terms:
|
| Conductor: | Bare Copper, Tinned Copper, Silver Plated Copper | Insulation: | HDPE |
|---|---|---|---|
| Jacket: | PVC | Cable Shape: | Round |
| Application: | Industrial, Comsumer Electrics, Medical, Etc | Packing: | Packed In Reels |
| Volatge: | 30V | Temperature: | 80℃ |
| HWATEK: | HT2302462 | ||
| High Light: | CAT 5e Twisted Pair Cable,80 °C 30V Cable,Twisted Pair 30V Cable |
||
CAT 5e S/FTP AWG26 x 4pairs TIA/EIA-568-B ,Twisted pair wires 80 °C 30V Cable
Product Description
Application: Internal wring or external interconnection of electronic equipment.
Application standard: None
Product character:
Flame rated : FT2
Tensile strength:≥10.3MPa Elongation:≥100%
Aged condition:113±1℃×168h
Percent of original tensile strength: ≥70%
Percent of original elongation: ≥65%
UL758 -E258652-20060111-CertificateofCompliance-1....
| ITEM | 4P×26AWG(7/0.16B) | ||||
| CONDUCTOR | Material | Bare copper stranded | |||
| Size | 7/0.16±0.008mm | ||||
| O.D.(Ref) | 0.48mm | ||||
| INSULATION | Material | HDPE | |||
| Min.average thickness | 0.18mm | ||||
| Min.thickness at any point | 0.15mm | ||||
| O.D. | 0.90±0.08mm | ||||
| TWISTED | O.D.(Ref) | 1.80mm | |||
| CABLING | Material | / | |||
| WRAPPED | Material | Al-mylar(face out) | |||
| DRIAN | Material | / | |||
| Size | / | ||||
| BRAID | Material | Tinned copper | |||
| Size | 0.10mm,≥85% | ||||
| JACKET | Material | PVC | |||
| Min.average thickness | 0.38mm | ||||
| Min.thickness at any point | 0.31mm | ||||
| O.D. | 5.20±0.20mm | ||||
Insulation:HDPE
Conductor : Bare copper stranded
Construction
Insulation:1.blue,white/blue 2.orange,white/orange 3.green ,white/green 4.brown,white/brown
Jacket : Gray
Jacket: PVC
Application
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines,
Standards
RoHS,REACH Compliant,
Technical data
Rated voltage:30V
Rated Temperature: 80℃
Flame: FT2
Voltage withstand test:AC 0.5kV/1min
Properties
Effectively resist electromaganetic interference
Excellent insulation performance
Extensively oil resistant
Flexible
| ELECTRICAL CHARACTERISTICS |
| Rated voltage:30V |
| Rated temperature:80℃ |
| Max. DC conductor resistance(20℃):140Ω/km |
| Voltage withstand test:AC 0.5kV/1min |
| Impedance:100±15Ω |
