HWATEK WIRES AND CABLE CO.,LTD.
|
Product Details:
Payment & Shipping Terms:
|
| Conductor: | Tinned Copper Stranded | Insulation: | PVC |
|---|---|---|---|
| Jacket: | PVC | Cable Shape: | Round |
| Application: | Industrial, Comsumer Electrics, Medical, Etc | Packing: | Packed In Reels |
| Volatge: | 30V | Temperature: | 60℃ |
| HWATEK: | HT2303013 | ||
| High Light: | Industrial Flexible Stranded Unshielded Cable,26AWG Tinned Copper Cable,PVC Jacket Insulation Industrial Flexible Cable |
||
30V PVC Jacket Tinned Copper Stranded unshield UL2835 3C×26AWG Cable
Product Description
Application: Internal wring or external interconnection of electronic equipment.
Application standard: Outdoor
Product character:
Flame rated : FT1
Tensile strength:≥10.3 MPa Elongation:≥100%
Aged condition:113±1℃×168h
Percent of original tensile strength: ≥70%
Percent of original elongation: ≥65%
UL758 -E258652-20060111-CertificateofCompliance-1....
| ITEM | 3C×26AWG(7/0.16T) | ||||
| CONDUCTOR | Material | Tinned copper stranded | |||
| Size | 7/0.16mm | ||||
| O.D.(Ref) | 0.48mm | ||||
| INSULATION | Material | PVC | |||
| Min.average thickness | 0.23mm | ||||
| Min.thickness at any point | 0.18mm | ||||
| O.D. | 1.00±0.08mm | ||||
| CABLING | Filler | Optional | |||
| Material | Non-woven | ||||
| Assembly | 3C×26AWG | ||||
| JACKET | Material | PVC | |||
| Min.average thickness | 0.76mm | ||||
| Min.thickness at any point | 0.61mm | ||||
| O.D. | 4.00±0.20mm | ||||
Insulation:PVC
Conductor : Tinned copper
Construction
Insulation: 1.yellow 2.green 3.red
Jacket : per request
Jacket: PVC
Application
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines,
Standards
International: NOUL
RoHS,REACH Compliant,
Technical data
Rated voltage:30V
Rated Temperature: 60℃
Flame: FT2
Voltage withstand test:AC 0.5kV/1min
Properties
Effectively resist electromaganetic interference
Excellent insulation performance
Extensively oil resistant
Flexible
| ELECTRICAL CHARACTERISTICS |
| Rated voltage:30V |
| Rated temperature:60℃ |
| Max. DC conductor resistance(20℃):150Ω/km |
| Voltage withstand test:AC 0.5kV/1min |
