UL20276 ( 30AWG * 1 Coax + SAJ) * 4 + 24AWG * 4C Shield OD 7.1mm , SUMITOMO#UL20002 Equivalent PVC Jacket Cable

UL20276 ( 30AWG * 1 Coax + SAJ) * 4 + 24AWG * 4C Shield OD 7.1mm , SUMITOMO#UL20002 Equivalent PVC Jacket Cable
UL20276 ( 30AWG * 1 Coax + SAJ) * 4 + 24AWG * 4C Shield OD 7.1mm , SUMITOMO#UL20002 Equivalent PVC Jacket Cable

Large Image :  UL20276 ( 30AWG * 1 Coax + SAJ) * 4 + 24AWG * 4C Shield OD 7.1mm , SUMITOMO#UL20002 Equivalent PVC Jacket Cable

Product Details:
Place of Origin: China
Brand Name: Hwatek
Certification: UL20276
Model Number: UL20276
Payment & Shipping Terms:
Minimum Order Quantity: 500m
Price: To be negotiated
Packaging Details: Packed in reels
Delivery Time: 4-6 Weeks
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 100KM per month
Detailed Product Description
Conductor: Tinned Copper Insulation: PVC
Jacket: PVC Cable Shape: Round
Application: Industrial, Comsumer Electrics, Medical, EV Charging, Green Energy Etc Packing: Packed In Reels
Volatge: 30V Temperature: -30~80℃
PN: HT2401266
High Light:

1 Coax UL20276 PVC jacket cable

,

4C UL20276 PVC jacket cable

,

24AWG UL20276 PVC jacket cable

UL20276 ( 30AWG * 1 Coax + SAJ) * 4 + 24AWG * 4C shield OD 7.1mm , SUMITOMO#UL20002 equivalent cable

Product Description

Construction
Conductor Tinned copper stranded
Cross section A:4×(1Caox×30AWG+SAJ) B:4C×24AWG
Construction 7/0.10mm 7/0.20mm
Strand Dia. 0.30mm 0.60mm
Insulation Foam PE ETFE
Nom.Thickness 0.40mm 0.10mm
Min.Thickness 0.32mm 0.08mm
Insulation Dia. 1.20±0.10mm 0.90±0.08mm
Insulation colour natural black,green,red,blue
Spiral Tinned copper /
Size 0.08mm,≥90% /
Material Al-mylar(face in) /
Inner jacket PVC /
Nom.Thickness 0.30mm /
Outer Dia. 2.20±0.15mm /
Colour black,green,red,blue /
Filler Optional
Material Paper tape
Braid Silver copper,0.10mm,≥80%
Assembly 4×(1CoaxX30AWG+SAJ)+4C×24AWG+PB
Jacket PVC
Nom.Thickness 0.51mm
Min.Thickness 0.43mm
Outer Dia. 7.10±0.30mm
Colour Black



UL20276 ( 30AWG * 1 Coax + SAJ) * 4 + 24AWG * 4C Shield OD 7.1mm , SUMITOMO#UL20002 Equivalent PVC Jacket Cable 0







UL20276 ( 30AWG * 1 Coax + SAJ) * 4 + 24AWG * 4C Shield OD 7.1mm , SUMITOMO#UL20002 Equivalent PVC Jacket Cable 1

Conductor Tinned copper stranded
Cross section
A:4×(1Caox×30AWG+SAJ) B:4C×24AWG
Construction 7/0.10mm, 7/0.20mm
Elongation ≥100%
Strand Dia.(Ref.)
0.3 mm, 0.60mm
Aged condition 113±1℃×168h
Insulation Foam PE, ETFE
Nom.Thickness 0.4mm , 0.10mm
Min.Thickness 0.32mm , 0.08mm
Insulation Dia. 1.20±0.10mm, 0.90±0.08mm
Insulation colour natural, black,green,red,blue
Assembly 4×(1CoaxX30AWG+SAJ)+4C×24AWG+PB
Jacket PVC
Reference standard:UL20276
Nom.Thickness 0.51mm
Min.Thickness 0.43mm
Outer Dia.
7.10±0.30mm
Colour per request

UL758-E258652-20060111A-CertificateofCompliance(2)...



ELECTRICAL CHARACTERISTICS
Rated voltage:30V
Rated temperature:-30~80
Max.conductor DC resistance(20℃)
A:381Ω/km, B:94.2Ω/km
Characteristic Impedance A(Nom.) 75Ω
Dielectric Strength AC: 0.5kV/1min



UL20276 ( 30AWG * 1 Coax + SAJ) * 4 + 24AWG * 4C Shield OD 7.1mm , SUMITOMO#UL20002 Equivalent PVC Jacket Cable 2UL20276 ( 30AWG * 1 Coax + SAJ) * 4 + 24AWG * 4C Shield OD 7.1mm , SUMITOMO#UL20002 Equivalent PVC Jacket Cable 0
