HWATEK WIRES AND CABLE CO.,LTD.
|
Product Details:
Payment & Shipping Terms:
|
| Conductor: | Bared Copper | Insulation: | PVC |
|---|---|---|---|
| Jacket: | PVC | Cable Shape: | Round |
| Application: | Industrial, Comsumer Electrics, Medical, EV Charging, Green Energy Etc | Packing: | Packed In Reels |
| Volatge: | 600V | Temperature: | -40~105℃ |
| PN: | HT2401365 | ||
| High Light: | stranded VCT Cable,Bared copper VCT Cable,600V VCT Cable |
||
| ITEM | 3C×2.0mm2(37/0.26B) | ||||
| CONDUCTOR | Material | Bared copper stranded | |||
| Size | 37/0.26mm | ||||
| O.D.(Ref) | 1.85mm | ||||
| INSULATION | Material | PVC | |||
| Min.average thickness | 0.76mm | ||||
| Min.thickness at any point | 0.69mm | ||||
| O.D. | 3.40±0.20mm | ||||
| CABLING | Filler | Optional | |||
| Material | |||||
| Assembly | 3C×2.0mm2(37/0.26B) | ||||
| BRAID | Material | / | |||
| Size | / | ||||
| JACKET | Material | PVC | |||
| Nom.average thickness | 1.80mm | ||||
| O.D. | 11.00±0.30mm | ||||
Conductor Bared copper stranded
Cross section 3C×2.0mm2(37/0.26B)
Construction 37/0.26B
Elongation ≥100%
Strand Dia.(Ref.) 1.85mm
Aged condition 136±1℃×168h
Insulation PVC
Nom.Thickness 0.76mm
Min.Thickness 0.69mm
Insulation Dia. 3.40±0.20mm
Insulation: 1.black 2.white 3.green/yellow
Jacket PVC
Reference standard:VCT standard
Nom.Thickness 1.8mm
Outer Dia. 11.00±0.30mm
Colour per request
UL758-E258652-20060111A-CertificateofCompliance(2)...
| ELECTRICAL CHARACTERISTICS | |
| Rated voltage:600V | |
| Rated temperature:-40~105℃ | |
| Max. DC conductor resistance(20℃):8.62Ω/km | |
| Bending radius:6×OD |
Company Profiles
Founded in 2004 with 9 million USD capital investment, our HQ factory in Kunshan covers 14980 square meters.
In 2020 we established our Nantong facility with 100 million RMB capital investment which covers 34000 square meters.
With ISO9001, ISO14001, IATF16949, ISO13485 system certificates, all of our products have passed CCC, UL, CUL, CE, CSA, ETL safety certificates. We are working with global customers in various fields through our well-established sales system based on the management principal HONESTY, INNOVATION and ENVIRONMENTAL PROTECTION.
Certificates
Production Progress
Shipping
FAQ
1. Q:What can you supply?
A: We do produce consumer electronics wires, hock up wires, industrial cables, robot cables, ev charging cables, new/green energy cables.
2. Q: What are the certificates do you get?
A: We have UL, CE, 3C, Dekra, CQC, TUV, Rohs, Reach, ETL certificates.
3. Q:Can we get samples before ordering?
A: Yes, we are willing to arrange samples for you.
4. Q: What's your lead time?
A: Normally we can finish you orders in 2-3 weeks, and 5-6 weeks in peak season.
5. Q. How can you guarantee the product quality?
A: Always a pre-production sample before mass production and final Inspection before shipment.
Major Customers
