Conductor: | Tinned Copper Stranded | Insulation: | PVC |
---|---|---|---|
Jacket: | PVC(UV Resistance) | Cable Shape: | Round |
Application: | Industrial, Comsumer Electrics, Medical, Etc | Packing: | Packed In Reels |
Volatge: | 1000V | Temperature: | -40~105℃ |
HWATEK: | HT2401942 | ||
Highlight: | 1000V PVC Bare Copper Stranded Cable,105℃ PVC Bare Copper Stranded Cable,UV resistance bare copper cable |
UL2586 TYPE PVC ( UV resistance ) Bare Copper Stranded 5C × 2.50 mm2 105℃ 1000V Cable
Product Description
Application: Internal wring or external interconnection of electronic equipment.
Application standard: Outdoor
Product character:
Flame rated : VW-1
Tensile strength:≥10.3MPa Elongation:≥100%
Aged condition:136±1℃×168H
Percent of original tensile strength: ≥70%
Percent of original elongation: ≥65%
UL758 -E258652-20060111-CertificateofCompliance-1....
Construction | ||
Conductor | Bare copper stranded wire | |
Cross section | 2.50mm2 | |
Construction | 140/0.15mm | |
Strand Dia. | 2.05mm | |
Insulation | PVC | |
Nom.Thickness | 0.76mm | |
Min.Thickness | 0.61mm | |
Insulation Dia. | 3.80±0.20mm | |
Insulation colour | 1-4 black,print number with white 1-4,5.green/yellow | |
Filler | Optional | |
Assembly | 5C×2.50mm2 | |
Material | Non-woven,≥25% | |
Jacket | PVC(UV resistance) | |
Nom.Thickness | 0.76mm | |
Min.Thickness | 0.61mm | |
O.D. | 12.70±0.50mm | |
Colour | black |
Insulation:PVC
Conductor : Bared copper stranded
Construction:
Jacket : per request
Jacket: PVC
Application
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines,
Standards
International: UL2586
RoHS,REACH Compliant,
Technical data
Rated voltage:1000V
Rated Temperature: -40~105℃
Flame: VW-1
Voltage withstand test:AC 3.0 kV/1min
Properties
Effectively resist electromaganetic interference
Excellent insulation performance
Extensively oil resistant
Flexible
Electric Performance | |
Rated Temperature | -40~105℃ |
Voltage rating | 1000V |
Max.conductor DC resistance(20℃) | 8.62Ω/km |
Dielectric Strength AC | 4.0kV/1min |
