UL2464 TYPE PVC Tinned Copper Stranded 24C×20AWG ( 7/0.32T )+ MB 80℃ 300V oil resistance Cable
Product Details
300V oil resistance Cable
UL2464 TYPE PVC Tinned Copper Stranded 24C×20AWG ( 7/0.32T )+ MB 80℃ 300V oil resistance Cable
Product Description
Application: Internal wring or external interconnection of electronic equipment.
Application standard: Outdoor
Product character:
Flame rated : VW-1
Tensile strength:≥10.3MPa Elongation:≥100%
Aged condition:113±1℃×168H
Percent of original tensile strength: ≥70%
Percent of original elongation: ≥65%
UL758 -E258652-20060111-CertificateofCompliance-1....
| ITEM | 24C×20AWG(7/0.32T)+MB | ||||
| CONDUCTOR | Material | Tinned copper stranded | |||
| Size | 7/0.32mm | ||||
| O.D.(Ref) | 0.96mm | ||||
| INSULATION | Material | SR-PVC | |||
| Min.average thickness | 0.23mm | ||||
| Min.thickness at any point | 0.18mm | ||||
| O.D. | 1.50±0.05mm | ||||
| CABLING | Filler | Optional | |||
| Material | Mylar,≥25% | ||||
| Assembly | 24C×20AWG(7/0.32T)+MB | ||||
| BRAID | Material | Tinned copper | |||
| Size | 0.15mm(85% nom.) | ||||
| JACKET | Material | PVC(oil resistance) | |||
| Min.average thickness | 0.76mm | ||||
| Min.thickness at any point | 0.61mm | ||||
| O.D. | 11.50±0.40mm | ||||
Insulation:SR-PVC
Conductor : Tinned copper stranded
Construction:
Jacket : per request
Jacket: PVC(oil resistance)
Application
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines,
Standards
International: UL2464
RoHS,REACH Compliant,
Technical data
Rated voltage:300V
Rated Temperature: -40~80℃
Flame: VW-1
Voltage withstand test:AC 2.0 kV/1min
Properties
Effectively resist electromaganetic interference
Excellent insulation performance
Extensively oil resistant
Flexible
| ELECTRICAL CHARACTERISTICS | |
| Rated voltage:300V | |
| Rated temperature:-40~80℃ | |
| Max. DC conductor resistance(20℃):36.7Ω/km | |
| Voltage withstand test:AC 2.0kV/1min | |
| Flame:VW-1 |
| PHYSICAL PROPERTIES | |||
| Tensile strength: | ≥10.3MPa | ||
| Elongation: | ≥100% | ||
| Aged condition: | 113±1℃×168h | ||
| Percent of original tensile strength: | ≥70% | ||
| Percent of original elongation: | ≥65% | ||
| Bending radius | Moving: | 15×OD | |
| Fixed: | 7.5×OD Checked |
||
