IEC 126 Standard Bared Copper Stranded 3C × 16 mm2 + 6C × 0.75 mm2 1500V IEC 62893-4-1 EVM Jacket 90 Deg Cable

Basic Properties
Place of Origin: China
Brand Name: Hwatek
Certification: IEC
Model Number: IEC 62893-4-1
Trading Properties
Minimum Order Quantity: 1000m
Price: To be negotiated
Standard Packaging: Packed in reels
Delivery Time: 4 Weeks
Payment Terms: T/T, L/C, Western Union,
Supply Ability: 100KM per month
Tags

electric vehicle charging cable

electric car charging cable

ev charging wire
Product Summary
IEC 126 Standard Bared Copper Stranded 3C × 16 mm2 + 6C × 0.75 mm2 1500V IEC 62893-4-1 EVM Jacket 90 Deg Cable Construction A:3C×16mm2 B:6C×0.75mm2 Conductor Bare copper stranded Cross section 16mm2 0.75mm2 Construction 511/0.20mm 40/0.15mm+Tinsel+ Kevlar Strand Dia.(Ref.) 5.60mm 1.30mm Insulation ...

Product Details

Conductor: Bared Copper
Insulation: EVI-2
Jacket: EVM-1
Cable Shape: Round
Application: Industrial, Comsumer Electrics, Medical, EV Charging, Green Energy Etc
Packing: Packed In Reels
Volatge: 1500V DC
Temperature: -40~90℃
PN: HT2201398
Product Description

IEC 126 Standard Bared Copper Stranded 3C × 16 mm2 + 6C × 0.75 mm2 1500V IEC 62893-4-1 EVM Jacket 90 Deg Cable

Construction
  A:3C×16mm2 B:6C×0.75mm2
Conductor Bare copper stranded
Cross section 16mm2 0.75mm2
Construction 511/0.20mm 40/0.15mm+Tinsel+ Kevlar
Strand Dia.(Ref.) 5.60mm 1.30mm
Insulation EVI-2
Nom.Thickness 0.80mm 0.40mm
Min.Thickness 0.64mm 0.32mm
Insulation Dia. 7.50±0.35mm 2.20±0.15mm
Insulation colour A1.red,A2.black,A3.green/yellow B1.orange&blue B2.white &violet B3.brown&gray

Filler PP rope
Tape Non woven
Assembly 3C×16mm2+3P×0.75mm2+W
Jacket EVM-1
Nom.Thickness 1.50mm
Min.Thickness 1.18mm
Outer Dia. 22.20±1.50mm
Colour Black





IEC 126 Standard Bared Copper Stranded 3C × 16 mm2 + 6C × 0.75 mm2 1500V IEC 62893-4-1 EVM Jacket 90 Deg Cable

Conductor Bared copper stranded
Cross section 3C×16.0mm2+2C×0.75mm2+W
Construction 511/0.20mm ,,40/0.15mm
Elongation ≥300%
Aged condition 110℃×168H
Insulation EVI-2
Nom.Thickness 0.8 mm
Min.Thickness 0.64 mm
Insulation Dia.7.5±0.35mm

nsulation: :A1.red,A2.black,A3.green/yellow

Jacket EVM-1
Reference standard:IEC standard
Nom.Thickness 1.5 mm
Outer Dia. 22.2±1.5mm
Colour per request

UL758-E258652-20060111A-CertificateofCompliance(2)...

Electric Performance
Rated Temperature -40~90℃
Voltage rating 1.5KV DC
Max.conductor DC resistance(20℃) A:1.21Ω/km
B:26Ω/km
Dielectric Strength AC 3.5kV/5min

IEC 126 Standard Bared Copper Stranded 3C × 16 mm2 + 6C × 0.75 mm2 1500V IEC 62893-4-1 EVM Jacket 90 Deg CableIEC 126 Standard Bared Copper Stranded 3C × 16 mm2 + 6C × 0.75 mm2 1500V IEC 62893-4-1 EVM Jacket 90 Deg CableIEC 126 Standard Bared Copper Stranded 3C × 16 mm2 + 6C × 0.75 mm2 1500V IEC 62893-4-1 EVM Jacket 90 Deg Cable



Company Profiles
Founded in 2004 with 9 million USD capital investment, our HQ factory in Kunshan covers 14980 square meters.
In 2020 we established our Nantong facility with 100 million RMB capital investment which covers 34000 square meters.
With ISO9001, ISO14001, IATF16949, ISO13485 system certificates, all of our products have passed CCC, UL, CUL, CE, CSA, ETL safety certificates. We are working with global customers in various fields through our well-established sales system based on the management principal HONESTY, INNOVATION and ENVIRONMENTAL PROTECTION.



Certificates
IEC 126 Standard Bared Copper Stranded 3C × 16 mm2 + 6C × 0.75 mm2 1500V IEC 62893-4-1 EVM Jacket 90 Deg Cable

Production Progress

IEC 126 Standard Bared Copper Stranded 3C × 16 mm2 + 6C × 0.75 mm2 1500V IEC 62893-4-1 EVM Jacket 90 Deg Cable

Shipping
IEC 126 Standard Bared Copper Stranded 3C × 16 mm2 + 6C × 0.75 mm2 1500V IEC 62893-4-1 EVM Jacket 90 Deg Cable

FAQ
1. Q:What can you supply?
A: We do produce consumer electronics wires, hock up wires, industrial cables, robot cables, ev charging cables, new/green energy cables.
2. Q: What are the certificates do you get?
A: We have UL, CE, 3C, Dekra, CQC, TUV, Rohs, Reach, ETL certificates.
3. Q:Can we get samples before ordering?
A: Yes, we are willing to arrange samples for you.
4. Q: What's your lead time?
A: Normally we can finish you orders in 2-3 weeks, and 5-6 weeks in peak season.
5. Q. How can you guarantee the product quality?
A: Always a pre-production sample before mass production and final Inspection before shipment.
