Custom External SCSI Cable High Density with Male to Female Connector

Custom External SCSI Cable High Density with Male to Female Connector
Custom External SCSI Cable High Density with Male to Female Connector Custom External SCSI Cable High Density with Male to Female Connector Custom External SCSI Cable High Density with Male to Female Connector

Large Image :  Custom External SCSI Cable High Density with Male to Female Connector

Product Details:
Brand Name: HWATEK
Certification: UL,CUL, CE,ROHS, REACH
Model Number: SCSI Cables
Payment & Shipping Terms:
Minimum Order Quantity: 6.1KM
Price: Negotiable
Packaging Details: carton/pallet
Delivery Time: 2-3W
Payment Terms: T/T
Detailed Product Description
Product Name: SCSI Cables Conductor: Sliver Copper Conductor
Standard: UL758,UL1581, UL2556,UL444,UL13 Insulation Material: PE
Shield Material: Copper Wire Braid Shield Or Al-Mylar Shield Sheath Material: FRPE
Application: Communication And Signal Control Systems Rated Voltage: 30V
Temperature: -20℃-80℃ Flame: VW-1,CMR,CM,CMG
Free Sample: YES
High Light:

flexible network cable

,

power and signal cable

SCSI Cables Halogen free ,High transmission speed, Good shielding property



Construction

Conductor :Sliver copper conductor
Insulation: PE

Shield or Braid: copper wire braid shield or Al-Mylar shield

Jacket: FRPE



Standards
International: UL758 , UL1581, UL2556,UL13,UL444

RoHS,REACH Compliant,



Technical data
Rated voltage:30V

Rated  Temperature:-20-80

Flame: VW-1,CMR,CM,CMG

Voltage withstand test:AC 0.5kV/1min





Properties

High transmission speed, Good shielding property

Excellent insulation performance

Halogen free

Technology parameter:



Impedance (at 20℃): 100±5Ω

Delay: 4.5 ns/m

Delay skew: Intra 10ps/m; Inter 50ps/m

Attenuation: Frequency( GHz)       Att. (dB/m)

                      0.625                           1.24

                      1.25                              1.7

                       1.5                               1.45

                       2.5                               1.98

                       3.75                             2.54

Specifications





Certificates



UL, CUL, CE



Packing and Shipping



  1. The cargo could be packaged as Hwatek’s standard requirement if client no special request, such as carton, wooden pallet or wooden case;
  2. If client put forward special packing requirements, Hwatek will specialize in custom materials and charge some fees;
  3. Hwatek’ll pack the cargo according to the transportation requirements strictly, including size, weight and safety;
  4. The cargo, manufacturer, packing details will be labeled on the outer packing;
  5. About transportation agent, Hwatek will give priority to customers' advice. If not, we can come up with some proposals and choose good and affordable agents for clients reference;
  6. Shipping term, It depends on the value of the goods and the will of the customer.
