PE Insulated Copper Wire Braid Shielded Cat5e LAN SFTP Cable for High Transmission Speed

Large Image : PE Insulated Copper Wire Braid Shielded Cat5e LAN SFTP Cable for High Transmission Speed

Product Details:

Certification:	ISO9001, CCC, RoHS

Payment & Shipping Terms:

Minimum Order Quantity:	3,000
Price:	0.5

Contact Now

Detailed Product Description

Conductor Material:	Copper	Sheath Material:	PVC Or Frpe
Insulation Material:	PE	Material Shape:	Round Wire
Rated Voltage:	30V	Rated Temperature:	-20ºC-80ºC
Flame Rating:	VW-1,CMR,CM,CMG	Voltage Test:	AC 0.5kV/1min
Impedance:	100±15	Return Loss:	20 DB
Attenuation:	1.80 DB/100m	NEXT:	67 DB
PSNEXT:	64 DB	ELFEXT:	66 DB
PSELFEXT:	63 DB
Highlight:	PE Insulated Cat5e LAN Cable , Copper Wire Braid Shielded SFTP Cable , High Transmission Speed Shielded Ethernet Cable

PE Insulated Copper Wire Braid Shielded Cat5e LAN SFTP Cable

Cable Construction

Conductor: Stranded or Solid, tinned, bare copper clad steel silvered plated copper conductor
Insulation: PE
Jacket: PVC or FRPE

Certification Standards

International: UL758, UL1581, UL2556, UL13, UL444, IEC61156, TIA568
RoHS, REACH Compliant

Technical Specifications

Rated Voltage: 30V
Rated Temperature: -20ºC to 80ºC
Flame Rating: VW-1, CMR, CM, CMG
Voltage Withstand Test: AC 0.5kV/1min

Performance Properties

High transmission speed
Excellent shielding properties
Superior insulation performance

Technical Parameters

Frequency MHz	Impedance	RL dB	Attenuation dB/100m	Next dB	PsNext dB	ElFext dB	PsElFext dB
0.772	100±15	20	1.80	67	64	66	63
1	100±15	20	2.04	65.3	62.3	63.8	60.8
4	100±15	23	4.05	56.3	53.3	51.7	48.7
8	100±15	24.5	5.76	51.8	48.8	45.7	42.7
10	100±15	25	6.46	50.3	47.3	43.8	40.8
16	100±15	25	8.24	47.3	44.3	39.7	36.7
20	100±15	25	9.26	45.8	42.8	37.7	34.7
25	100±15	24.3	10.42	44.3	41.3	35.8	32.8
31.25	100±15	23.3	11.72	42.9	39.9	33.9	30.9
50	100±15	21.74	15.06	37.2	37.2	30.24	27.24
62.5	100±15	20.7	16.99	38.4	35.4	27.8	24.8
100	100±15	19	21.97	35.3	32.3	23.8	20.8
