Single Core Flexible Cable
Display Port Consumer Electrical Hook Up Wire PE
Display Port Consumer Electronics Hook Up Wire PE Basic Info. Material Shape Round Wire Range of Application Medical Equipment Certification ISO9001, UL, CCC, RoHS Brand Hwatek Color Optional Qty/Roll 305m, 610m or as Request Transport Package Rolled in Reels, Packed in Pallets. Trademark Hwatek ...
Oil Resistant UL1569 300V Single Core Flexible Cable Hook Up Wire
UL1569 Single Core Flexible Cable Hook-Up Wire Product Number Conductor Insulation Max. Cond. Resistance (200C) Ω/km Min insulation resistance (200C) MΩ/km Dielectric Strength (AC) V/1min Size AWG NO./mm Conductor Dia . mm Nom. Thickness mm Nom. Dia. mm HT1201595 30 7/0.1 0.30 0.38 0.82 381 15 2000 ...
UL1354 30V Single Core Flexible Cable Hook Up For Internal Wiring
UL1354 Single Core Flexible Cable Hook-Up Wire Application: For internal wiring of electronic product Application standard: UL758&UL1581&CSA C22.2 No.210 Product character: Standard insulation thickness, easily strip and cut Pass UL VW-1 and CSA FT1 vertical flame test Oil resistance, anti-acid, ...
Hook Up Single Core Flexible Cable Oil Resistance UL1032
UL1032 Single Core Flexible Cable Hook-Up Wire Product Number Conductor Insulation Max. Cond. Resistance (200C) Ω/km Min insulation resistance (200C) MΩ/km Dielectric Strength (AC) V/1min Size AWG NO./mm Conductor Dia . mm Nom. Thickness mm Nom. Dia. mm HT10321**001 30 7/0.1 0.30 0.80 1.90 354 15 ...
Tinned Conductor Single Core Flexible Cable Hook Up Wire UL1185
UL1185 Single Core Flexible Cable Hook-Up Wire Product Number Conductor Insulation Spiral Shield Jacket Max. Cond. Resistance (200C) Ω/km Size AWG NO./mm Conductor Dia . mm Nom. Thickness mm Nom. Dia. mm No./mm Nom. Dia. mm Nom. Thickness mm Nom. Dia. mm HT1185**001 30 7/0.1 0.30 0.43 1.16 30/0.1 1...
Moisture Proof Single Core Flexible Cable PVC Insulation UL1015
UL1015 Single Core Flexible Cable Product Number Conductor Insulation Max. Cond. Resistance (200C) Ω/km Min insulation resistance (200C) MΩ/km Dielectric Strength (AC) V/1min Size AWG NO./mm Conductor Dia . mm Nom. Thickness mm Nom. Dia. mm HT1201525 30 7/0.1 0.30 0.76 0.82 381 15 2000 HT1201526 28 ...
High Flexible Single Core Electrical Cable PUR Sheath Heat Resistant Halogen Free
High Flexible Single core TPE Sheath cable,Halogen Free 105 ℃, 600V,VW-1 Construction Conductor : stranded, tinned or bare copper, IEC60228 CL5 Insulation:PP, TPEE Sheath:PUR Standards International: UL758 , UL1581, UL2556 RoHS,REACH Compliant, Technical data Rated voltage:600 V Rated Temperature:...
Flexible PVC Insulated Single Core Wire / PUR Sheath Cable 80 ℃ 1000V Scratch Proof
High Flexible Single core PVC insulation,PUR Sheath cable,80 ℃, 1000V Construction Conductor : stranded, tinned or bare copper, IEC60228 CL5 Insulation:Special PVC Sheath:PUR Standards International: UL758 , UL1581, UL2556 RoHS,REACH Compliant, Technical data Rated voltage:1000 V Rated Temperature:...
Industrial PUR Single Core Flexible Cable Cold Resistant Halogen Free UV - Radiation
PUR Single Core , cold resistant, halogen-free,UV-radiation Construction Conductor : stranded, tinned or bare copper, IEC60228 CL5 Insulation:PUR Standards International: UL758 , UL1581, UL2556 RoHS,REACH Compliant, Technical data Rated voltage:300 V Rated Temperature:-40~80℃ Flame: VW-1, FT1, FT2 ...
