30V 80ºC Medical Equipment Coaxial Ultrasound Cable for Diagnostic Devices

Large Image : 30V 80ºC Medical Equipment Coaxial Ultrasound Cable for Diagnostic Devices

Product Details:

Certification:	ISO9001, CCC, RoHS

Payment & Shipping Terms:

Minimum Order Quantity:	3,000
Price:	0.5

Contact Now

Detailed Product Description

Conductor Material:	Copper	Sheath Material:	Pet
Insulation Material:	PFA	Material Shape:	Round Wire
Rated Voltage:	30V	Rated Temperature:	80ºC
Conductor AWG:	30-46AWG	Shield Material:	Tinned Copper
Jacket Material:	PFA Or PET	Impedance:	45-80 Ω
Max Resistance:	1569-12000 Ω/km	Conductor Construction:	Stranded Or Silver-plated Or Tinned Alloy Copper
Insulation Dia.:	0.175-0.46 Mm	Jacket Dia.:	0.29-0.54 Mm
Quantity Per Roll:	305m, 610m Or As Request
Highlight:	30V Coaxial Ultrasound Cable , 80ºC Medical Coaxial Cable , Medical Equipment Coaxial Power Cable

30V 80ºC Special Medical Equipment Coaxial Ultrasound Cable

Products are used in electrocardiograph instruments, ultrasound imaging systems, CT scanners, and medical diagnostic devices.

Product Specifications

Product Number	AWG	Conductor Material	Conductor Construction	Conductor Dia. (mm)	Insulation Material	Nom. Insulation Dia. (mm)	Shield Material	Shield Dia. (mm)	Jacket Material	Nom. Jacket Dia. (mm)	Impedance (Ω)	Max Resistance (Ω/km)
HTMMC0001	36	TC	7/0.05	0.15	PFA	0.38	TC	0.03	FEP	0.54	45	1569
HTMMC0002	38	SPTCA	7/0.04	0.12	PFA	0.3	TC	0.025	FEP	0.44	45	3300
HTMMC0003	38	SPTCA	7/0.04	0.12	FEP	0.35	TC	0.03	PET	0.44	50	3300
HTMMC0004	38	SPTCA	7/0.04	0.12	PFA	0.46	TPTCA	0.025	PET	0.54	80	3300
HTMMC0005	40	SPTCA	7/0.03	0.09	PFA	0.22	TC	0.025	FEP	0.36	45	5000
HTMMC0006	40	TC	7/0.03	0.09	PFA	0.25	TC	0.03	PET	0.34	50	5000
HTMMC0007	40	SPTCA	7/0.03	0.09	PFA	0.38	TPTCA	0.025	PET	0.46	80	5000
HTMMC0008	42	SPTCA	7/0.025	0.08	PFA	0.175	TC	0.025	PFA	0.30	45	7500
HTMMC0009	42	SPTCA	7/0.025	0.08	PFA	0.345	TPTCA	0.025	PET	0.43	80	7500
HTMMC0010	44	SPTCA	3/0.03	0.06	PFA	0.175	TPTCA	0.025	PFA	0.29	50	12000

Application

Internal wiring of medical diagnostic devices.

Product Characteristics

Small diameter, lightweight design with excellent strength and bending resistance
Specifically designed for internal connections in medical devices
PFA insulation material provides superior heat resistance and stable electrical performance

Cable Structure

Stranded, silver-plated, or tinned alloy copper conductor (30-46AWG)
PFA insulation
Spiral shielding with tinned copper
PFA or PET jacket

Technical Parameters

Rated temperature: 80ºC
Rated voltage: 30V
