EV Charging Cable
Customized 42 AWG Medical Device Cable with Silver Plate Copper PTFE Sheath and PFA Insulation
Customized 42 AWG and 75 Ohms Medical Device Cables Product Specifications Conductor: Silver plate copper alloy Jacket Size: 42AWG Construction: 7/0.025mm Strand Dia: 0.075mm Insulation: Foam PFA Nom.Thickness: 0.10mm Insulation Dia: 0.27±0.05mm Insulation colour: Natural Spiral Tinned copper alloy, ...
1000V High Voltage DC Electric EV Charging Cable with TPU Insulation and RoHS Compliant Multicore Design
1000V HV High Voltage EV Power Charger Multicore DC Electric Wire Cable Product Specifications SPECIFICATION CABLE NAME EV Cable CABLE SPEC 2C×80mm2+1C×25mm2+2C×4mm2+(3C×0.75mm2)(P2)+(7C×0.75mm2)RoHS Compliant Item A: 2C×80mm2 B: 1C×25mm2 C: 1C×4mm2 D: (3C×0.75mm2)(P2) E: (7C×0.75mm2) Detailed ...
450V/750V AC/DC EV Charging Cable with 2 X 50mm2+35mm2+6X0.75mm2 Copper Conductor for Electric Vehicles
450V/750V AC/DC EV Charging Cable 2 X 50mm²+35mm²+6X0.75mm² Basic Specifications Cable Specification: 200A, 70mm² Power: 1x50mm² Black Core + 1x50mm² Red Core PE: 1x35mm² Green-Yellow Core Signal: 3x Pairs 2x0.75mm² Cores Color: Orange, Blue, White, Violet, Brown, Grey Sheath Outer Diameter: ~31mm ...
3C×10AWG+2C×18AWG 600V 105ºC EV Charging Cable with TPE Insulation and Bare Copper Stranded
Eve 3c5.0mm2 and 2c*0.8mm2 Cable Product Specifications Item Unit A: 3C×10AWG Unit B: 2C×18AWG Conductor Material Bare Copper Stranded Size 105/0.254±0.008mm 65/0.127±0.008mm Pitch (Ref) 59mm Max. 32mm Max. O.D. (Ref) 3.00mm 1.18mm Insulation Material TPE Min. Average Thickness 1.14mm 0.76mm Min. ...
RoHS & Reach Compliant AC 450/750V and DC Multicore EV Charging Cable with IEC60332-1 Flammability Test and Minimum Bending Radius 5xOD
RoHS & Reach Compliant AC 450/750V and DC Multicore HV EV Power Charging Cables Quality Certification Certificate No. Product Types CQC16011142377 EV-(R)SS, EV-(R)SSPS, EV-(R)S90S90, EV-(R)S90S90PS90, EV-(R)S90U, EV-(R)S90S90PU-450/750V Structure Diagram Reference Standard GB/T 33594-2017 Product ...
High Voltage Flame Retardant EV Charging Cable with PVC Sheath and Round Wire for Medical Equipment
Eve, Evjt High Voltage Flame Retardant Power Charging Copper Wire Cable Type Conductor Insulation Jacket Max. Cond. Resistance(20ºC)Ω/km EVJE EVJT(300V) 18 AWG2-6C41/0.16 0.76 mm 0.76 mm 0-8.89 16 AWG2-6C26/0.254, 65/0.16 0.76 mm 1.52 mm 11.5-14.0 14 AWG2-6C41/0.254 0.76 mm 2.41 mm 23.0-31.7 12 AWG2...
Evc H07bz5-F 450 750V EV Charging Cable Insulated EV charging cable type 2
Evc H07bz5-F 450 750V EV Charging Cable Product Description EVC H05BZ5-F EVC H07BZ5-F 300/500V TüV certified electric vehicle charging cable Certification Body : Technischer Überwachungs-Verein Certificate No. Product Types R 50471285 EVC H05BZ5-F EVC H07BZ5-F R 50488767 62893 IEC 126 Structure ...
IEC 126 Standard Bared Copper Stranded 3C × 16 mm2 + 6C × 0.75 mm2 1500V IEC 62893-4-1 EVM Jacket 90 Deg Cable
IEC 126 Standard Bared Copper Stranded 3C × 16 mm2 + 6C × 0.75 mm2 1500V IEC 62893-4-1 EVM Jacket 90 Deg Cable Construction A:3C×16mm2 B:6C×0.75mm2 Conductor Bare copper stranded Cross section 16mm2 0.75mm2 Construction 511/0.20mm 40/0.15mm+Tinsel+ Kevlar Strand Dia.(Ref.) 5.60mm 1.30mm Insulation ...
UL3133 16mm2 Bare Copper Stranded Silicone 600V 150℃ EV Battery Motorcycles Charging Cable
UL3133 16 mm2 Bared Copper Stranded Silicone 600V 150℃ EV battery motorcycles charging cable Product Description Application: Internal wring or external interconnection of electronic equipment. Application standard: Outdoor Product character: Flame rated : FT2 Rated Temperature 150℃ Voltage rating ...
